Basic Parameters
Height: 207.1mm
Width: 134.2mm
Depth: 6.9mm
Weight: 363g
Material: Metal Frame + Glass-accented Back Cover
Color: Starfrost (Silver), Eclipse (Black)
Memory Combination: Eclipse. 12 + 256 GB, 16 +512 GB, Starfrost. 12 + 256 GB, 16 +512 GB
LPDDR5X + UFS 4.1
Display
Size: 9.06-inch OLED
Refresh Rate: Up to 185Hz
Touch Sampling Rate: 2,000Hz Instant Peak / 300Hz Average
Resolution: 2,400 x 1,504 Pixels
Pixel Density: 313 PPI
Aspect Ratio: 16:10
Type: OLED
Brightness: 1,600 nits peak, 1,100 nits full-screen brightness
Material: Corning® Gorilla® Glass
Color Accuracy: DCI-P3
Color Accuracy ΔE ≈ 0.7 (Golden)
Eye Protection: SGS Low Blue Light & Flicker-Free Certified
Splash, Water, and Dust Resistant: IP54 Rating
Cooling System
AquaCore Cooling System 2.0
Under-Screen Cooling Alloy
Under-Screen High-Conductivity Graphene
Under-Screen High-Conductivity Copper Foil
Large Vapor Chamber
Motherboard Copper Foil
Motherboard Cooling System
High-Thermal-Conductivity Gel
Durable High-Strength Aluminum Alloy Mid-Frame
Liquid Metal 3.0
Graphene Layer
High-Conductivity Copper Foil
AquaCore Liquid Cooling Cycle
Hardware
Snapdragon 8 Elite Gen 5
CPU Cores: Oryon™
CPU up to 4.6GHz
GPU: Adreno™
RedCore R4
Capacity*
RAM: 12GB / 16GB LPDDR5X
ROM: 256GB / 512GB UFS 4.1
*Actual memory space is less and varies due to many factors
Connectivity
Wi-Fi: 802.11 a/b/g/n/ac/ax/be
Bluetooth: Bluetooth 6.0
HDMI: Converter Needed
DP: Supports Up to 4K@144fps / Up to 8K@60fps HD Video
Cameras
Rear Camera
Resolution: 13MP, with Enhanced AI Algorithm
5P Lens, Up to 4K@30fps Video Recording
Front Camera
Resolution: 9MP, with Enhanced AI Algorithms
φ1.9mm - The Smallest Front Camera on a Tablet
4P Lens, 1080P@30fps
ƒ/2.2 aperture
0.7μm 4-in-1 Pixel
Sensor
Gyroscope, geomagnetic sensor, ambient light sensor, Hall sensor, fingerprint sensor, accelerometer.
Operating System
REDMAGIC OS 11.5 is based on Android 16
Battery & Quick Charging
Battery: 8,300mAh Dual Cell Battery
Fast Charge: Up to 75W
Ports
Dual USB-C Ports — Audio Supported, Fast Charging Up to 75W
Short-side: USB-C 3.2 Gen 2 with DisplayPort
Long-side: USB-C 2.0
*Disclaimer: The 75W charging data is obtained under laboratory testing conditions. Actual charging performance may vary depending on device settings, battery condition, ambient temperature, usage scenarios, and other environmental factors. Actual results may differ.
Audio Supported Formats
Playback: WAV, AAC, MP3, FLAC
Storage: MP3, MPEG-4, Matroska, FLAC, 3GPP
Recording: MP3
DTS:X® Ultra. Stereo dual 1227 speakers. N'Bass acoustic enhancement materials
Video Supported Formats
Playback: MP4, MKV, WEBM
Recording: MP4
Video Codec Support
Decoder:
3840 × 2160 @ 240fps
4096 × 2160 @ 240fps
7680 × 4320 @ 60fps
8190 × 4320 @ 60fps
Encoder:
3840 × 2160 @ 120fps
7680 × 4320 @ 60fps
Image Supported Formats
Playback: JPEG, PNG, GIF, BMP, WBMP, HEIC
Storage: JPEG
Special Functions
Magic Key: By default, it launches the GameSpace, but users can customize it for quick access to other functions such as taking photos or recording videos with the rear camera, enabling the flashlight, launching the voice recorder, activating face-to-face translation, or switching to mute or vibration mode.
RGB Light: Fully Customizable Lighting Effects
Haptics: Dual 0815 X-axis Linear Motors
In the Box
REDMAGIC Astra 2 Gaming Tablet ×1
Type-C Cable ×1
Warranty Card ×1
User Manual ×1
Logo Sticker ×1
Please note: Charger is not included with this tablet.
Disclaimer：
1. All product data, including but not limited to display dimensions (such as narrow bezels, screen size, device width, weight, and thickness), is based on measurements conducted in REDMAGIC internal laboratories under controlled conditions. Actual results may vary due to differences in color variants, testing environments, measurement methods, manufacturing processes, and other factors. Please refer to the actual product.
2. All performance-related data, including cooling efficiency, charging speed, and other system performance metrics, is derived from REDMAGIC internal laboratory testing under specific controlled conditions. Actual performance may vary depending on individual product differences, software versions, usage patterns, network conditions, and environmental factors. Actual user experience may differ.
3. Battery capacity refers to the typical value of 8, 300mAh for the REDMAGIC Astra 2 Gaming Tablet. Actual battery life may vary depending on network conditions, application usage, feature settings, call and message frequency, charging habits, and other factors.
4. The 75W charging data is obtained under laboratory testing conditions. Actual charging performance may vary depending on device settings, battery condition, ambient temperature, usage scenarios, and other environmental factors. Actual results may differ.
5.Devices are tested under controlled laboratory conditions and achieve an IP54 rating. The air duct adopts an independent cooling structure; dust may enter during operation but does not affect core functions or overall performance under normal use. Water, splash, and dust resistance are not permanent conditions and may decline over time due to normal wear and tear. Do not charge the device while it is wet.
6. A portion of internal storage is occupied by system software, including the Android operating system and pre-installed applications. Therefore, available storage capacity is lower than the stated total capacity and may vary depending on software updates and device configuration.
7. High refresh rate performance (e.g., 185Hz gaming mode) may vary depending on game optimization progress. Some features may be gradually rolled out or require adaptation by individual games. Actual support may differ based on game versions, regional releases, and in-game conditions.
8. Photo and video resolutions may vary depending on selected shooting or recording modes. Please refer to actual device performance.
9. External factors, including running applications, network quality, and environmental conditions, may affect data transmission speed, screen performance, and overall user experience.
10. Device performance may be influenced by external conditions and usage environments.
11. Wi-Fi performance may vary depending on local network quality.
12. Images are for illustrative purposes only. Actual product may vary.
13. All data is sourced from REDMAGIC internal laboratories under specified test conditions. Actual results may vary.
